Technical Specifications
- Lead: Standard 12 leads
- Input circuit: protection against defibrillator
- Acquisition Mode: Simultaneous 12 leads acquisition and asynchronous acquisition; Measurement Range: ±5mVpp
- Time Constant ≥3.2s;
- Frequency Response: 0.05Hz~150Hz (-3dB);
- Sensitivity: 2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV
- Input Impedance ≥50MΩ;
- Input Circuit Current <0.05μA
- Noise Level < 15μVp-p;
- Patient Current Leakage <10μA (220V-240V)
Filter:
- EMG Filter: 25 Hz / 30 Hz / 40Hz
- Low Pass Filter: 75 Hz / 100 Hz / 150Hz
- DFT Filter: 0.05 Hz/0.15 Hz/0.25 Hz/0.32 Hz/ 0.5 Hz/ 0.67Hz/ ADS
- AC Filter: 50 Hz / 60Hz
- CMRR: 100dB;
Recording Mode:
- Automatic: 3CH×4+1R, 3CH×4, 6CHx2
- Manual: 4CH, 3CH, 2CH, 1CH
- Rhythm: Any lead selectable
- Recording System: Thermal matrix printing
- Recording Paper: Roll 110mmx20M
- Paper Speed: 6.25 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s
- Interface: Network interface, USB Master/Slave, SD card;
- Safety Standard: IEC I/CF
Power Supply:
- AC : 100~240V, 50/60Hz, 30VA~100VA
- DC: 14.8V/2200Ah,built-inlithiumbattery
