Chison CBit 6 Colour Doppler Ultrasound Trolley with a 21.5-inch Monitor
A Chison colour Doppler ultrasound system on wheels, with a 21.5-inch HD LED monitor that rotates up to 90 degrees, colour flow (CFM) and power Doppler with B, B/M, M, 2B and 4B modes, and 4 active probe connectors. The touch panel, 4D, CW and the probes themselves are chosen with you for your work. The physician chooses the probe and the exam.
1-year warranty
On Chison devices, from the date of purchase.
Lifetime service
With genuine spare parts after the warranty too.
Accredited maintenance centre
By the General Authority for Industrial Control.
Ali Ben Ali
In the medical equipment trade since 1987, with 4 branches.
This device may suit you if...
The final choice is made with the physician or the biomedical engineering team. These are the uses the device is made for.
A centre or hospital with many specialties on one system
Abdomen, OB/GYN, small parts, paediatrics, vascular, musculoskeletal and cardiac.
The examiner uses several probes a day
4 active probe connectors, so switching needs no unplugging.
You need 4D, CW or a touch panel
They are added to your order, and we agree the configuration with you before you order.
Colour Doppler shows the direction and speed of blood in the vessels, in colour, over the black-and-white image. On the CBit 6, colour flow and power Doppler are part of the system; additions like the touch panel, 4D and CW are chosen to fit your work.
CBit 6 features
21.5-inch HD LED monitor
The image takes about 90% of the screen, with a full-screen mode; the monitor rotates up to 90 degrees each way.
Colour flow and power Doppler
With B, B/M and M modes, plus dual (2B) and quad (4B) display.
4 active probe connectors
For convex, linear, micro-convex, transvaginal, transrectal, phased-array and 4D volume probes.
A cleaner image
Compound imaging, SRA speckle reduction and LGC lateral gain control.
Configured to your order
A 10.1-inch HD touch panel with dual-screen display, 4D and CW Doppler.
A comfortable control panel
Full keyboard with backlit keys, a built-in speaker, 6 USB ports and Ethernet.
Technical specifications
Imaging
- System type
- Console colour Doppler system on wheels
- Scanning modes
- B, B/M, M, dual (2B), quad (4B), colour flow (CFM) and power Doppler
- Transducer connectors
- 4 active probe connectors
- Transducer types supported
- Convex, linear, micro-convex, transvaginal, transrectal, phased array and a volume probe for 4D
- Imaging and measurement tools
- Compound imaging for a cleaner image, SRA speckle reduction, LGC lateral gain control, full keyboard with backlit keys and a built-in speaker
- Configured to your order
- A 10.1-inch HD touch panel with dual-screen display, 4D with a volume probe, CW Doppler, and the probes themselves
Display
- Screen size
- 21.5 inch
- Monitor tilt
- Rotates up to 90 degrees each way
- Display
- 21.5-inch HD LED monitor, image on about 90% of the screen, full-screen mode
Data & connectivity
- Inputs and outputs
- 6 USB ports, Ethernet, VGA and DVI, S-Video and video out, printer remote, audio L/R, 2 foot-switch ports
Power
- Power input
- 100–240 V AC, 50/60 Hz, 600 VA
Physical
- Dimensions
- 810 × 635 × 1330 mm
- Weight
- 76 kg
Warranty & after-sales
- Ali Ben Ali warranty
- 1 year
Identity
- Specialties
- Abdomen, OB/GYN and fetal, small parts (breast, thyroid), paediatrics, peripheral vascular, musculoskeletal, adult and paediatric cardiac, transvaginal
Compare with other Ultrasound system devices
| CBit 6This page | QBit 3Go to product | |
|---|---|---|
| System type | Console colour Doppler system on wheels | Slim-console colour Doppler system on wheels |
| Scanning modes | B, B/M, M, dual (2B), quad (4B), colour flow (CFM) and power Doppler | B, B/M, M, dual (2B) and quad (4B) |
| Screen size | 21.5 inch | 15 inch |
| Monitor tilt | Rotates up to 90 degrees each way | Rotates up to 90 degrees each way and folds down up to 90 degrees |
| Transducer connectors | 4 active probe connectors | 2 probe connectors; 4 as an option |
| Configured to your order | A 10.1-inch HD touch panel with dual-screen display, 4D with a volume probe, CW Doppler, and the probes themselves | Colour Doppler (Color and Power) and PW licences, a 19-inch monitor instead of 15-inch, 4 probe connectors instead of 2, and the probes themselves |
| Dimensions | 810 × 635 × 1330 mm | 747 × 517 × 1283 mm |
| Weight | 76 kg | 50 kg |
| Ali Ben Ali warranty | 1 year | 1 year |
A dot next to a value means it differs from the device on this page.
Frequently asked questions
About the CBit 6
What is the difference between the CBit 6 and the QBit 3?
The CBit 6 has a 21.5-inch monitor and 4 probe connectors, colour flow and power Doppler are part of it, and a touch panel, 4D and CW can be added. The QBit 3 is a slimmer console with a 15-inch monitor and 2 probe connectors, and its colour Doppler is a licence chosen with the order. For cardiac or 4D work, the CBit 6 is the closer fit.
Who operates the system and chooses the probe?
The physician or sonographer. They choose the probe and the exam for the organ. The probes supplied with the system are agreed with you according to your specialty; contact us on WhatsApp or the hotline 01212333328.
Where do extra probes and spare parts come from?
The system accepts convex, linear, micro-convex, transvaginal, transrectal, phased-array and 4D volume probes. Order any extra probe or spare part from customer service on 01212333328; we service the system for its whole life.
What power does it need?
Standard mains from 100 to 240 V, 50/60 Hz, with a 600 VA rating. It weighs about 76 kg and moves on wheels.
Do the touch panel and 4D come with the system?
They are additions set with the order, like CW and the probes. Tell us what you scan, and we will agree the right configuration with you before you order.
About buying medical devices from Ali Ben Ali
Is the device genuine, and how can I be sure?
The device is made by Chison and comes with the Ali Ben Ali warranty; we have been in the medical equipment trade since 1987. You can also see it in person at any of our branches before you buy.
About usHow long is the warranty, and who provides it?
1 year from Ali Ben Ali from the date of purchase, on Chison devices. We honour it directly, not through a third party; for any coverage question call the hotline 01212333328.
Maintenance centresIf the device breaks after the warranty, who repairs it?
Our maintenance centre at 31 El Rashidy St – Kasr El Aini, accredited by the General Authority for Industrial Control. Service and genuine spare parts stay available for the device's whole life.
Maintenance centresCan I return or exchange the device?
Yes, within 14 days of delivery, if it is unused, complete with its accessories and in its original packaging. If it arrives defective or different from your order, we replace it or refund it in full. Masks, tubing and any items that contact the patient cannot be returned once opened, for hygiene reasons. Return shipping is on us for a defect or a wrong item; otherwise the customer pays it, unless a free-shipping offer applies.
Exchange and returns policyDo you deliver and install? Should I buy online or at a branch?
We deliver and install in 27 governorates within Egypt. Shipping fees are set after you order and agreed with you by phone or WhatsApp before dispatch. Order on the website or on WhatsApp, or visit our branches: Rashidy and Bostan in Cairo, Alexandria and Mansoura.
