Chison QBit 3 Slim-Console Colour Doppler Ultrasound System
A Chison ultrasound system on a slim console with wheels, with a 15-inch LED monitor that rotates and folds, and B, B/M, M, 2B and 4B modes. The colour Doppler and PW licences, a 19-inch monitor, 4 probe connectors instead of 2, and the probes themselves are chosen with you for your work. The physician chooses the probe and the exam.
1-year warranty
On Chison devices, from the date of purchase.
Lifetime service
With genuine spare parts after the warranty too.
Accredited maintenance centre
By the General Authority for Industrial Control.
Ali Ben Ali
In the medical equipment trade since 1987, with 4 branches.
This device may suit you if...
The final choice is made with the physician or the biomedical engineering team. These are the uses the device is made for.
A clinic or centre that wants a console system in a small footprint
A slim console on wheels that moves between rooms without effort.
You want only the configuration you need
Colour Doppler, PW, the larger monitor and the probe connectors are chosen with you.
Many specialties on one system
Abdomen, OB/GYN, vascular, musculoskeletal, small parts, urology and paediatrics.
The QBit 3 comes with the core imaging modes (B, M, 2B and 4B); colour Doppler, which shows the direction and speed of blood in colour, is added as a licence to your order. You choose the configuration your work actually needs, and we set it with you before you order.
QBit 3 features
Slim console on wheels
Replaceable probe holder, cable management and a front-facing printer socket.
15-inch LED monitor
Rotates up to 90 degrees each way and folds down up to 90 degrees; the keyboard rotates up to 45 degrees.
Core imaging modes
B, B/M and M, plus dual (2B) and quad (4B) display.
A clearer image with less adjustment
Trapezoidal imaging for a wider field, compound imaging for a cleaner image, and AIO automatic optimisation.
Configured to your order
Colour Doppler (Color and Power) and PW licences, a 19-inch monitor, and 4 probe connectors instead of 2.
Connection and file transfer
6 USB 2.0 ports, LAN for DICOM and a PC printer, VGA and DVI for an external monitor.
Technical specifications
Imaging
- System type
- Slim-console colour Doppler system on wheels
- Scanning modes
- B, B/M, M, dual (2B) and quad (4B)
- Transducer connectors
- 2 probe connectors; 4 as an option
- Transducer types supported
- Convex, linear, micro-convex, transvaginal, transrectal and phased array
- Imaging and measurement tools
- Trapezoidal imaging for a wider field, compound imaging for a cleaner image, AIO automatic image optimisation, general measurement package
- Configured to your order
- Colour Doppler (Color and Power) and PW licences, a 19-inch monitor instead of 15-inch, 4 probe connectors instead of 2, and the probes themselves
Display
- Screen size
- 15 inch
- Monitor tilt
- Rotates up to 90 degrees each way and folds down up to 90 degrees
- Display
- 15-inch LED monitor, keyboard rotating up to 45 degrees each way
Data & connectivity
- Inputs and outputs
- 6 USB 2.0 ports, LAN for DICOM and a PC printer, VGA and DVI for an external monitor, S-Video for a video printer, foot-switch ports
Power
- Power input
- 100–240 V AC, 50/60 Hz, 600 VA
Physical
- Dimensions
- 747 × 517 × 1283 mm
- Weight
- 50 kg
Warranty & after-sales
- Ali Ben Ali warranty
- 1 year
Identity
- Specialties
- Abdomen, OB/GYN, vascular, musculoskeletal, small parts, urology and paediatrics
Compare with other Ultrasound system devices
| QBit 3This page | CBit 6Go to product | |
|---|---|---|
| System type | Slim-console colour Doppler system on wheels | Console colour Doppler system on wheels |
| Scanning modes | B, B/M, M, dual (2B) and quad (4B) | B, B/M, M, dual (2B), quad (4B), colour flow (CFM) and power Doppler |
| Screen size | 15 inch | 21.5 inch |
| Monitor tilt | Rotates up to 90 degrees each way and folds down up to 90 degrees | Rotates up to 90 degrees each way |
| Transducer connectors | 2 probe connectors; 4 as an option | 4 active probe connectors |
| Configured to your order | Colour Doppler (Color and Power) and PW licences, a 19-inch monitor instead of 15-inch, 4 probe connectors instead of 2, and the probes themselves | A 10.1-inch HD touch panel with dual-screen display, 4D with a volume probe, CW Doppler, and the probes themselves |
| Dimensions | 747 × 517 × 1283 mm | 810 × 635 × 1330 mm |
| Weight | 50 kg | 76 kg |
| Ali Ben Ali warranty | 1 year | 1 year |
A dot next to a value means it differs from the device on this page.
Frequently asked questions
About the QBit 3
What is the difference between the QBit 3 and the CBit 6?
The QBit 3 is a slim console with a 15-inch monitor and 2 probe connectors (4 as an option); its colour Doppler is a licence chosen with your order. The CBit 6 has a 21.5-inch monitor and 4 probe connectors, colour flow and power Doppler are part of it, and a touch panel, 4D and CW can be added. For cardiac or 4D work, the CBit 6 is the closer fit.
Who operates the system and chooses the probe?
The physician or sonographer. They choose the probe and the exam for the organ. The probes supplied with the system are agreed with you according to the clinic's specialty; contact us on WhatsApp or the hotline 01212333328.
Where do extra probes and spare parts come from?
The system accepts convex, linear, micro-convex, transvaginal, transrectal and phased-array probes. Order any extra probe or spare part from customer service on 01212333328; we service the system for its whole life.
What power does it need?
Standard mains from 100 to 240 V, 50/60 Hz, with a 600 VA rating. It weighs about 50 kg without probes and moves on wheels.
Can I choose colour or the larger monitor?
The colour Doppler and PW licences, the 19-inch monitor and the 4 probe connectors are all set with the order. Tell us what you scan, and we will agree the right configuration with you before you order.
About buying medical devices from Ali Ben Ali
Is the device genuine, and how can I be sure?
The device is made by Chison and comes with the Ali Ben Ali warranty; we have been in the medical equipment trade since 1987. You can also see it in person at any of our branches before you buy.
About usHow long is the warranty, and who provides it?
1 year from Ali Ben Ali from the date of purchase, on Chison devices. We honour it directly, not through a third party; for any coverage question call the hotline 01212333328.
Maintenance centresIf the device breaks after the warranty, who repairs it?
Our maintenance centre at 31 El Rashidy St – Kasr El Aini, accredited by the General Authority for Industrial Control. Service and genuine spare parts stay available for the device's whole life.
Maintenance centresCan I return or exchange the device?
Yes, within 14 days of delivery, if it is unused, complete with its accessories and in its original packaging. If it arrives defective or different from your order, we replace it or refund it in full. Masks, tubing and any items that contact the patient cannot be returned once opened, for hygiene reasons. Return shipping is on us for a defect or a wrong item; otherwise the customer pays it, unless a free-shipping offer applies.
Exchange and returns policyDo you deliver and install? Should I buy online or at a branch?
We deliver and install in 27 governorates within Egypt. Shipping fees are set after you order and agreed with you by phone or WhatsApp before dispatch. Order on the website or on WhatsApp, or visit our branches: Rashidy and Bostan in Cairo, Alexandria and Mansoura.
