Specifications
- User friendly keypad design
- Embedded handle allows for easy transportation
- Intuitive programming procedure with quick guidance on screen
Infusion Safety
- Dynamic pressure system – monitors the pressure in real time. Ability to change the 3-level clog sensitivity threshold
3 levels of alarms
Easy to use
- Low weight and comfortable handle
- Built-in battery for operation without external power supply
- Remember last saved settings after shutdown
- Quick start of the infusion
Versatility:
- Work with all types and sizes of syringes
- Easy installation
- Waterproof membrane – IP34
- Self-diagnosis – Motor, Sensor, Battery, Memory card, CPU
- Automatic and manual lock on the keyboard
- High degree of accuracy
Functions:
- Titration, Keypad lock, Pause, Automatic syringe size recognition
Features:
| screen | 2.5 “LCD |
| Alarms for | end of infusion, near solution, blockage, low battery level, critically low battery level, syringe displacement, lack of power supply, malfunction, error |
| Alarms Volume Level | Adjustment (8 Degrees) |
| Power supply | AC 100-240V, 50 / 60Hz |
| Rechargeable battery | Lithium, up to 5 hours of autonomous operation at 5 ml / h |
| Dimensions | 360 (L) x 145 (W) x 123 (H) mm |
| Weight | <2 kg |
Infusion rate:
| 5 Ml Syringe | (0.1 ~ 150) Ml / H; 10 Ml Syringe: (0.1 ~ 300) Ml / H; 20ml Syringe: (0.1 ~ 600) Ml / H 30 Ml Syringe: (0.1 ~ 900) Ml / H; 50 Ml / 60 Ml Syringe: (0.1 ~ 1500) Ml / H |
| Infusion Volume | 0.1 – 999.9 Ml |
| Bolus | 0.10-1500 Ml / H |
| Compatible | With 5, 10, 20, 30, 50 Et 60 Ml Syringes |
| VTBI | From 0.1 To 999.9 Ml |
| Accuracy | +/- 2% |
| Bolus Rate | De 0.10 To 1 500 Ml/H |
| KVO Rate | 0.5 Ml/H |
| Automatic Detection Of | Syringe Type |
| Occlusion |
|
| Flow Rate Range |
|
DISPLAY
- Flow rate
- Accumulated injection volume
- Preset volume
- Syringe size
- Battery capacity
- AC power indicator
- Battery charge indicator
ALARM
- VTBI done, VTBI near done
- KVO finish
- Occlusion
- Syringe empty, syringe near empty, syringe not installed
- System error, system abnormal
- Battery low, battery empty
- AC power disconnection
ERGONOMY
- 2.5” LCD screen
- Embedded handle for easy transportation
- Anti-free flow clamp
- Dimensions: 360 x 145 x 123 mm
- Weight: 1.95 kg
