Yuwell 7E-G1 Portable Phlegm Suction Unit That Works Without Mains Power, with Built-In Battery and Car Cable
A portable Yuwell phlegm suction unit that works without mains power: the built-in battery runs it for at least 60 minutes, and it also runs from a car lighter socket or the mains. It gives 85 kPa of suction and draws 27 L/min, and its 1000 mL jar has an overflow valve. The doctor or paramedic sets the suction level.
1-year warranty
On Yuwell devices, from the date of purchase.
Lifetime service
With genuine spare parts after the warranty too.
Accredited maintenance centre
By the General Authority for Industrial Control.
Ali Ben Ali
In the medical equipment trade since 1987, with 4 branches.
This device may suit you if...
The unit is used by someone trained on it, and the doctor sets the right suction. These are the uses the device is made for.
An ambulance or patient transport
It runs from the car lighter socket with the cable supplied.
Power cuts or no mains at all
The built-in battery runs it for at least 60 minutes.
Emergencies anywhere
Portable and light: 4 kg.
This unit runs three ways: mains 100–240 V, a 12 V car lighter socket, or the built-in battery. kPa is suction strength and L/min is flow speed: 85 kPa and 27 L/min.
7E-G1 features
Built-in battery
Runs it for at least 60 minutes at maximum vacuum, charges in about 4 hours, and charges while running on mains.
Runs from a car
A cable for the 12 V car lighter socket. The socket powers the unit only; it does not charge the battery.
85 kPa suction
Set from 20 kPa to maximum vacuum, with 27 L/min flow, classified High vacuum / high flow.
Overflow protection
A valve in the jar stops suction by itself when full, followed by an air filter.
Battery indicator
Lights show the charge level and warn when the battery is running low.
Oil-free pump
1000 mL jar; weight 4 kg.
Technical specifications
Safety
- Reflux protection
- Overflow valve that stops suction automatically when the jar is full, followed by an air filter
- Electrical safety class
- Class II and internal power, type B applied part
Therapy
- Maximum vacuum
- 85 kPa±5 kPa
- Vacuum adjustment range
- 20 kPa to maximum vacuum
- Free air flow
- 27 L/min±4, at the device inlet
- ISO 10079-1 class
- High vacuum / high flow
- Duty cycle
- 30 min on, 30 min off
Comfort
- Sound level
- 65 dBmaximum, dB(A)
Power
- Power input
- Mains 100–240 V, 50/60 Hz, or 12 V DC from a car lighter socket, or the built-in battery
- Electrical input power
- 150 VA
- Battery runtime
- 60 minminimum, at limit vacuum
- Battery charging time
- About 4 hours from the mains; it charges while running on mains. The car lighter socket does not charge the battery
- Water ingress protection
- IPX0
Physical
- Weight
- 4 kg
- Dimensions
- 480 × 189 × 285 mmas printed
Warranty & after-sales
- Ali Ben Ali warranty
- 1 year
Identity
- Type
- Portable, with battery
- Pump
- Oil-free pump
- Collection jars
- 1 × 1000 mL jar
- Specialties
- Emergencies and places without mains power, including in a vehicle
Compare with other Surgical suction unit devices
| 7E-G1This page | 7E-AGo to product | 7A-23BGo to product | |
|---|---|---|---|
| Type | Portable, with battery | Portable | On castors |
| Maximum vacuum | 85 kPa (±5 kPa) | 85 kPa (±10 kPa, at 760 mmHg) | 90 kPa (±10 kPa, at 760 mmHg) |
| Free air flow | 27 L/min (±4, at the device inlet) | 20 L/min (minimum, at the device inlet) | 20 L/min (minimum, at 760 mmHg) |
| ISO 10079-1 class | High vacuum / high flow | High vacuum / high flow | High vacuum / high flow |
| Pump | Oil-free pump | Oil-free pump | Oil-free piston pump |
| Duty cycle | 30 min on, 30 min off | 30 min on, 30 min off | 30 min on, 30 min off |
| Collection jars | 1 × 1000 mL jar | 1 × 1000 mL jar | 2 × 2500 mL glass jars |
| Reflux protection | Overflow valve that stops suction automatically when the jar is full, followed by an air filter | Overflow valve that stops suction automatically when the jar is full, followed by an air filter | Jar A has an overflow valve that stops suction automatically when full; jar B acts as a buffer before the pump; then an air filter |
| Sound level | 65 dB (maximum, dB(A)) | 65 dB (maximum, dB(A)) | 60 dB (maximum, dB(A)) |
| Electrical input power | 150 VA | 90 VA | 180 VA |
| Battery runtime | 60 min (minimum, at limit vacuum) | – | – |
| Weight | 4 kg | 4 kg (approx.) | 17 kg |
| Dimensions | 480 × 189 × 285 mm (as printed) | 280 × 196 × 285 mm (L × W × H) | 350 × 305 × 795 mm (L × W × H) |
| Ali Ben Ali warranty | 1 year | 1 year | 1 year |
A dot next to a value means it differs from the device on this page.
Frequently asked questions
About the 7E-G1
What is the difference between the 7E-G1 and the 7E-A?
The 7E-G1 has a built-in battery, runs from a car lighter socket and draws 27 L/min. The 7E-A runs on mains power only and draws at least 20 L/min. Both have a 1000 mL jar and 85 kPa of suction.
Who sets the suction strength?
The doctor or paramedic, according to the patient. Suction is set with a knob from 20 kPa to maximum vacuum.
What if the battery weakens or needs replacing?
If the unit is unused for a long time, charge and discharge the battery once a month. Battery replacement is done by a trained technician: call customer service on 01212333328.
What power supply does it need?
Mains 100–240 V, 50/60 Hz, or 12 V from a car lighter socket, or the built-in battery. Power consumption is 150 VA, and charging is from the mains only.
Can it run non-stop?
It runs 30 minutes on and 30 minutes off. Before switching off, lower the suction below 20 kPa, and empty and wash the jar after each use.
About buying medical devices from Ali Ben Ali
Is the device genuine, and how can I be sure?
The device is made by Yuwell and comes with the Ali Ben Ali warranty; we have been in the medical equipment trade since 1987. You can also see it in person at any of our branches before you buy.
About usHow long is the warranty, and who provides it?
1 year from Ali Ben Ali from the date of purchase, on Yuwell devices. We honour it directly, not through a third party; for any coverage question call the hotline 01212333328.
Maintenance centresIf the device breaks after the warranty, who repairs it?
Our maintenance centre at 31 El Rashidy St – Kasr El Aini, accredited by the General Authority for Industrial Control. Service and genuine spare parts stay available for the device's whole life.
Maintenance centresCan I return or exchange the device?
Yes, within 14 days of delivery, if it is unused, complete with its accessories and in its original packaging. If it arrives defective or different from your order, we replace it or refund it in full. Masks, tubing and any items that contact the patient cannot be returned once opened, for hygiene reasons. Return shipping is on us for a defect or a wrong item; otherwise the customer pays it, unless a free-shipping offer applies.
Exchange and returns policyDo you deliver and install? Should I buy online or at a branch?
We deliver and install in 27 governorates within Egypt. Shipping fees are set after you order and agreed with you by phone or WhatsApp before dispatch. Order on the website or on WhatsApp, or visit our branches: Rashidy and Bostan in Cairo, Alexandria and Mansoura.
Branches and contactCustomer reviews
