DS Maref DVT-2600 Intermittent Pneumatic Compression Pump
A DS Maref pump that inflates and deflates leg sleeves with air at intervals, using sleeves with 3 chambers inflated in sequence, 20 to 60 mmHg on the leg and 120 to 140 mmHg on the foot, in DVT and LYMPH modes. The doctor sets the pressure, the mode and the treatment time.
1-year warranty
On DS Maref devices, from the date of purchase.
Accredited service centre
By the General Authority for Industrial Control, at 31 El Rashidy St – Kasr El Aini.
Genuine product
By DS Maref.
Ali Ben Ali
In the medical equipment trade since 1987, with 4 branches.
This device may suit you if...
These are the uses the device is made for.
You run a surgical ward or an ICU
Intermittent air compression of both legs at the settings the doctor chooses.
You need two modes in one pump
DVT and LYMPH.
You want a pump that moves between beds
It weighs 2 kg and has a built-in battery.
Intermittent pneumatic compression in one line: the pump inflates the sleeve's chambers one after another, then releases them, and repeats every 28, 48 or 60 seconds.
See the device on video
The manufacturer's device video · DVT-2600DVT-2600 features
3-chamber sleeves
Inflated in sequence.
Leg and foot pressure
20–60 mmHg on the leg, 120–140 mmHg on the foot.
Cycle interval
28, 48 or 60 seconds.
Built-in battery
DC 10.89 V, 3350 mAh.
2 kg
200 × 165 × 190 mm.
Automatic calibration
Of the pressure sensor at power-on and in use.
Technical specifications
Compression
- Modes
- DVT and LYMPH
- Sleeve pressure
- Leg: 20–60 mmHg; foot: 120–140 mmHg; 10 mmHg steps (±15 mmHg)
- Interval time
- 28, 48 or 60 seconds
- Sleeves
- Sleeves with 3 air chambers, inflated in sequence
Safety
- Safety controls
- Automatic pressure-sensor calibration at power-on and during operation
Power
- Battery
- Built-in battery, DC 10.89 V, 3350 mAh
- Power input
- 100–240 V AC, 50/60 Hz; 90–110 VA
- Water ingress protection
- IPX2
Physical
- Weight
- 2 kg
- Dimensions
- 165 × 200 × 190 mm
Warranty & after-sales
- Ali Ben Ali warranty
- 1 year
Identity
- Type
- Intermittent pneumatic compression pump for the legs
Frequently asked questions
About the DVT-2600
What is the difference between DVT and LYMPH mode?
They are the two modes DS Maref sets for the pump; the doctor chooses the right one for each patient.
Who sets the pressure and the treatment time?
The doctor. Pressure is set in 10 mmHg steps and the cycle interval is 28, 48 or 60 seconds.
Which sleeves come with it?
Sleeves with 3 air chambers. For the sleeve types and sizes supplied with the pump, call the hotline 01212333328 and we will confirm them with you.
What power does it need?
100–240 V, 50/60 Hz, with a built-in DC 10.89 V, 3350 mAh battery.
Is it splash-resistant?
Its water-ingress protection is IPX2.
About buying medical devices from Ali Ben Ali
Is the device genuine, and how can I be sure?
The device is made by DS Maref and comes with the Ali Ben Ali warranty; we have been in the medical equipment trade since 1987. You can also see it in person at any of our branches before you buy.
About usHow long is the warranty, and who provides it?
1 year from Ali Ben Ali from the date of purchase, on DS Maref devices. We honour it directly, not through a third party; for any coverage question call the hotline 01212333328.
Maintenance centresIf the device needs service, who repairs it?
Our maintenance centre at 31 El Rashidy St – Kasr El Aini, accredited by the General Authority for Industrial Control. Call the hotline 01212333328 and we will set a time with you.
Maintenance centresCan I return or exchange the device?
Yes, within 14 days of delivery, if it is unused, complete with its accessories and in its original packaging. If it arrives defective or different from your order, we replace it or refund it in full. Masks, tubing and any items that contact the patient cannot be returned once opened, for hygiene reasons. Return shipping is on us for a defect or a wrong item; otherwise the customer pays it, unless a free-shipping offer applies.
Exchange and returns policyDo you deliver and install? Should I buy online or at a branch?
We deliver and install in 27 governorates within Egypt. Shipping fees are set after you order and agreed with you by phone or WhatsApp before dispatch. Order on the website or on WhatsApp, or visit our branches: Rashidy and Bostan in Cairo, Alexandria and Mansoura.
